Features

• Anterior & Posterior
• 3000 CPM / 7500 CPM
• 500 mmHg Venturi Aspiration
• Phaco / 23g Fragmatome
• Independent Dual LED Light Source
• 23/25g Capability
• SOI/SOR & GF/IP
• Linear/Fixed/Dual Settings

Anterior Segment Menu

• DIA – DIATHERMY
• US1 – PHACO 1
• US2 – PHACO 2
• US3 – PHACO 3
• I/A – IRRIGATION / ASPIRATION
• CAP/VAC
• VIT – VITRECTOMY
• I/P – INFUSION PRESSURE

Posterior Segment Menu

• DIA – DIATHERMY
• VIT – VITRECTOMY
• SOI – SILICONE OIL INJECTOR
• SOR – SILICONE OIL REMOVER
• FRAG1 – FRAGMATOME 1
• FRAG2 – FRAGMATOME 2
• G/F – GAS / FLUID EXCHANGER
• I/P – INFUSION PRESSURE

Diathermy

• 10 Watts High precision power output
• Variable power setting from 05-100% at a step of 5
• Output Short circuit protection
• Bipolar Micro forceps and pencil eraser
• 3 Modes Linear, Fixed and Dual

Aspiration

• High Precision Pedal controlled Linear Venturi Aspiration
• Real time Vacuum achieved by Hi caliber sensor based Software
• Vacuum level range from 05-500 mmHg at a step of 05 mmHg
• Preset value : Programmable and recall facility
• 3 Modes Linear, Fixed and Dual

Reflux

• Forced Positive Reflux
• Reflux force can be adjustable

Phaco / Fragmatome

• Ultrasonic power generation at 40 KHz – 4 Crystal
• Phaco / Fragmatome enabled for Continuous , Pulse, Burst and Cold modes
• Pulse selection from 1 to 15 pulse
• Burst and Cold modes with On- Off Time adjustable
• U/S Power from 05- 100% : Linear, Fixed and Dual
• Ultra Advanced Processor based and continuously auto tuned
• Ultrasonic / Effective usage time display
• Preset value : Programmable and recall facility
• 3 Modes Linear, Fixed and Dual

Vitrectomy

• Pneumatically powered from external Air Compressor
• Cutter speed selection from 60-3000 Cuts Per Minute
• Optional 7500 Cuts Per Minute
• Vitrectomy RDY/OFF control through foot switch
• 4 Modes Linear, Fixed, Dual & Single cutting
• 20 g / 23 g / 25 g Compatability

Illumination

• Twin LED Lamp 23 g & 25 g capability
• Matching adapter to suit most types of cables
• Adjustable power from 0-100% illumination
• 100% UV / IR Free Source
• LED Life Expectency is more than 1 Lac Hours
• Can be used for Chandlier Purpose (Dual Source)

Gas/Fluid Exchanger & I/P (Infusion Pressure)

• 01-100 mmHg at a step of 01mmHg accuracy for G/F
• 01-120 mmHg at a step of 01mmHg accuracy for I/P
• Real time closed loop regulated output
• Foot Switch Enabled I/P Temponade Control

Visco Fluid Injector / Remover

• Compatible with all types of Visco fluid like 1000 CST to 5000CST
• Variable pressure range from 05-100 %
• Variable vacuum range from 05- 600 mmHg
• Linear pedal controlled Visco fluid Injection / Extraction
• 3 Modes Linear, Fixed and Dual

Foot Switch

• Easy maneuverable
• Dedicated Vitrectomy and US (on-off) / Reflux control switches
• Menu selection through Foot switch with voice prompt
• 4 Programmable Independent Switches

Display

• Dual Display – 10.4” Touch Display / 4.3” TFT Display

Control Panel

• Simple layout
• External Keypad
